Electro-DPSU-Power-supply

Power Supply – DPSU

R540.29

Switch mode power supply for regulated DC supply.



Features:



  • Switch mode power supply
  • High Stability
  • Low ripple
  • Fast response time
  • Modular 35.5mm DIN rail mountable
  • LED indication for power supply ON
Clear selection
Category:

Description

Output Specifications

Output Specifications
5 VDC
9 VDC
12 VDC
24 VDC
Ripple Voltage ≤ 2%
Output Power ± 25VA
Line Regulation ± 5%
Output Variation ≤ 0.5% / V
within rated power supply and ambient temperature ≤ 0.2% / °C

Supply Specifications

Power Suppy AC Type 95-260Vzc
(Galvanic) 50 / 60 Hz ± 5Hz
Isolation 4kV
Consumption ± 3VA

General Specifications

Power ON Delay ≤ 300 ms
Power OFF Delay ≤ 3 sec
Indication for
Power Supply ON LED green
Environment
Degree Of protection IP 20
Operating Temperature -10 to + 50°C
Storage Temperature -50 to + 85°C
Weight 200g

Additional information

Output

12Vdc, 24Vdc, 9Vdc, 10Vdc, 5Vdc
