Power Supply Unit – PSU

R235.65

Power Supply Unit – PSU



Features:



  • Overload Protection
  • Short-circuit Protection
  • Over Temperature shut down
  • Stable supply with low ripple factor
  • Power supply ON LED
Clear selection
Category:

Description

Input Specifications

Output Specifications

Standard Output Voltage 5, 9, 10, 24 VDC
Output Power 2VA
Ripple Voltage < 2%
Overload Protection yes

Supply Specifications

Power Suppy AC Type (Galvanic) 110, 230, 400V, 525V ± 10% 50 / 60 Hz ± 5Hz
Isolation 4kV
Consumption ± 3VA
±6 VA 525 V

General Specifications

Power ON Delay ≤ 300 ms
Power OFF Delay ≤ 200 ms
Indication for
Power ON LED red
Environment
Degree Of protection IP 20
Operating Temperature -10 to + 50°C
Storage Temperature -50 to + 85°C
Weight 200g

Additional information

Supply Voltage

400Vac, 230Vac, 110Vac, 48Vac, 24Vac, 12Vac
Output

12Vdc, 24Vdc, 9Vdc, 10Vdc, 5Vdc
