Back to New Modular Din-Rail
DIN-DVC

Voltage Converter – DVC

R583.30

Features:



  • Analogue Microprocessor controlled
  • 10 bit resolution
  • High linearity
  • Fast response time
  • Modular 35.5mm DIN rail mountable
  • LED indication for power supply ON
  • NON-ISOLATED
Clear selection
Category:

Description

Input Specifications

Input Ranges 0 – 5VDC
0 – 10VDC
0 – 400VAC
0 – 600VAC
Isolation None

Output Specifications

Output Specifications
4 – 20mA
0 – 20mA
1 – 5VDC
0 – 10VDC

Supply Specifications

Power Suppy AC Type 110, 230, 400V, 525V ± 10%
(Galvanic) 50 / 60 Hz ± 5Hz
Isolation 4kV
Consumption ± 3VA
±6 VA 525 VA

General Specifications

Power ON Delay ≤ 300 ms
Power OFF Delay ≤ 200 ms
Indication for
Power Supply ON LED green
Environment
Degree Of protection IP 20
Operating Temperature -10 to + 50°C
Storage Temperature -50 to + 85°C
Weight 200g

Additional information

Input/Monitoring

0-10VDC, 0-600Vac, 0-400Vac, 0-230Vac, 0-110Vac, 0-5VDC
Supply Voltage

525Vac, 400Vac, 230Vac, 110Vac
Output

0-20mA, 0-5VDC, 4-20mA, 0-10VDC, 1-5VDC
